降雨诱发的浅表堆积层滑坡成因机理与稳定性预测模型

刘佳意; 陈春利; 付昱凯; 王晨兴; 李同录; 肖锐铧; 刘艳辉

doi:10.16030/j.cnki.issn.1000-3665.202306051

降雨诱发的浅表堆积层滑坡成因机理与稳定性预测模型

doi: 10.16030/j.cnki.issn.1000-3665.202306051

刘佳意^{1, 2,},
陈春利^3, ,,
付昱凯^{1, 2},
王晨兴¹,
李同录^{1, 2},
肖锐铧³,
刘艳辉³

1.
长安大学地质工程与测绘学院，陕西西安　710054
2.
黄土高原水循环与地质环境野外科学观测研究站，甘肃正宁　745399
3.
中国地质环境监测院，北京　100081

基金项目: 国家重点研发计划项目（2021YFE0111900）, 国家自然科学基金项目（No. 42207213），陕西省自然科学基础研究计划项目（2022JM-167)。

详细信息

作者简介:
刘佳意（1999-），女，硕士生，主要从事工程地质与地质灾害研究。E-mail：652042569@qq.com

通讯作者:
陈春利（1987–），女，博士，高级工程师, 主要从事工程地质与地质灾害研究。E-mail: chen_chunli@126.com

中图分类号: P642.22
计量
- 文章访问数: 21
- HTML全文浏览量: 9
- PDF下载量: 9
- 被引次数: 0
出版历程
- 收稿日期: 2023-06-28
- 录用日期: 2023-10-13
- 修回日期: 2023-10-13

Mechanism of rainfall-induced shallow landslide and stability prediction model

LIU Jiayi^{1, 2
,},
CHEN Chunli^{3
, ,},
FU Yukai^{1, 2},
WANG Chenxing¹,
LI Tonglu^{1, 2},
XIAO Ruihua³,
LIU Yanhui³

1.
College of Geological Engineering and Geomatics, Chang’an University, Xi’an, Shangxi　710054
2.
Observation and Research Station of Water Cycle and Geological Environment for the Chinese Loess Plateau, Ministry of Education, Zhengning, Gansu　745399, China
3.
China Institue of Geo-Environment Monitoring, Beijing　100081, China

摘要

摘要: 强降雨引起的滑坡多以浅表堆积层滑移为主，易群发、危害性大，其地下水和土体内部含水率对降雨的水文响应机制复杂，难以精准开展稳定性预测。为研究降雨引起的滑坡水文响应对滑坡稳定性的影响，以四川省青川县后山里滑坡为例，开展现场降雨入渗监测、相关性分析和力学分析。通过连续三年的降雨量、土体水分和地下水位等监测，分析了降雨入渗-土体体积含水率-地下水位的响应规律，建立了降雨量与地下水位的相关关系，并基于无限斜坡稳定性计算公式构建了基于降雨量和地下水位埋深的浅层滑坡稳定性预测模型。结果表明：（1）年内地下水呈周期性波动，分为缓慢下降期、快速下降期和快速上升期三个阶段，且降雨量与地下水埋深呈线性负相关，与水位升幅相关性不显著；（2）根据稳定性预测模型确定了该滑坡失稳的临界降雨阈值81.8 mm/d和地下水埋深阈值0.73 m。研究结果可为降雨诱发浅表堆积层滑坡的预警预报提供参考。
- 堆积层滑坡 /
- 降雨量 /
- 地下水位 /
- 滑坡稳定性 /
- 预警
Abstract: The rainfall-induced shallow landslides are primarily debris landslides, characterized by chain-mass occurrence and high hazard, and the hydrological response mechanism of water table and soil moisture content to precipitation is complicated, which makes it difficult to accurately carry out the stability prediction. To further study the influence of the rainfall-triggered internal hydrological responses on the slope-stability, on-site precipitation infiltration monitoring, correlation analysis and mechanical analysis were carried out on the example of Houshanli landslide in Qingchuan County, Sichuan Province. The relationship between precipitation and water table was proposed based on three years of climate and hydrological monitoring data. The response of rainfall infiltration, soil volumetric water content and water table were analyzed. The results indicate that: (1) groundwater exhibits periodic fluctuations throughout the year, characterized by three phases of slow decline, rapid decline, and rapid ascent. Additionally, there is a linear negative correlation between precipitation and water table, with no significant correlation observed with the water table increment; (2) Through the infinite slope model and the relationship between precipitation and water table, a prediction model for shallow landslide stability was constructed. The precipitation threshold (81.8 mm/d) and water table threshold (0.73 m) were determined which align with the actual situations. This provides an early warning method for rainfall-induced shallow landslides by monitoring these two factors.
- debris landslide /
- precipitation /
- water table /
- landslide stability /
- early warning

HTML全文

图 1 四川青川后山里滑坡

Figure 1. Houshanli landslide in Qingchuan county, Sichuan province

下载: 全尺寸图片幻灯片

图 2 后山里滑坡监测现场布置

Figure 2. Monitoring site of the Houshanli landslide

下载: 全尺寸图片幻灯片

图 3 粒径级配曲线

Figure 3. Particle size distribution curve

下载: 全尺寸图片幻灯片

图 4 降雨-土体体积含水率-地下水位的对应关系

Figure 4. Corresponding relationship between rainfall, volumetric water content and water level

下载: 全尺寸图片幻灯片

图 5 降雨强度-地下水位深度的关系

Figure 5. Corresponding relationship between rainfall and groundwater level

下载: 全尺寸图片幻灯片

图 6 地下水位升幅随日降雨量的关系变化

Figure 6. Groundwater level rising vs. daily precipitation

下载: 全尺寸图片幻灯片

图 7 地下水埋深随日降雨量变化

Figure 7. Groundwater depth vs. daily precipitation

下载: 全尺寸图片幻灯片

图 8 无限边坡模型

Figure 8. Model of infinite slope

下载: 全尺寸图片幻灯片

图 9 2020-2022年降雨集中期降雨量与地下水位埋深及其阈值

Figure 9. Precipitation and water depth during raining period from 2020 to 2022 and their thresholds

下载: 全尺寸图片幻灯片

图 10 2020-2022年降雨集中期后山里滑坡滑移现象

Figure 10. Sliding of HouShanli landslide during raining period from 2020 to 2022

下载: 全尺寸图片幻灯片

表 1 7月—8月主要降雨事件中降雨量及其引起的地下水位变化参数

Table 1. Daily Precipitation and the related groundwater level variation in July and August

日期	水位升幅当日降雨量/mm	降雨前初始水位埋深/m	降雨截止最高水位深度/m	水位升幅/m
2020/7/10*	29.9	2.59	2.55	0.04
2020/7/24*	83.9	2.40	0.65	1.75
2020/7/25*	16.3	1.32	0.97	0.35
2020/7/29*	21.0	1.93	1.64	0.29
2020/7/30	13.4	1.65	1.50	0.15
2020/8/5*	69.6	1.94	0.92	1.02
2020/8/6	21.8	1.41	1.20	0.21
2020/8/11	134.2	1.92	0.51	1.41
2020/8/12	103.7	1.24	0.62	0.62
2020/8/14	14.4	1.46	1.36	0.10
2020/8/15	80.6	1.49	0.81	0.68
2020/8/16	127.3	0.87	0.62	0.25
2020/8/17	111.2	0.90	0.54	0.36
2020/8/22	20.4	1.36	1.25	0.11
2020/8/23*	41.5	1.19	1.16	0.03
2020/8/30	44.1	1.57	0.90	0.67
2021/7/10*	52.6	2.68*	2.44	0.24
2021/7/14	47.5	2.10	1.88	0.22
2021/8/16*	21.6	2.93	2.91	0.02
2021/8/17*	54.2	2.93	1.74	1.19
2021/8/18*	124.1	1.68	0.85	0.83
2021/8/19*	12.7	1.31	1.08	0.23
2021/8/21*	15.2	1.65	1.54	0.11
2021/8/22	14.6	1.41	1.30	0.11
2022/7/12*	62.4	2.62	2.45	0.17
2022/7/13*	54.9	2.42	1.13	1.29
2022/7/14*	50.4	1.51	0.63	0.88
2022/7/16	17.2	1.70	1.28	0.42
2022/7/22*	22.1	2.00	1.81	0.19
2022/7/27*	19.6	2.12	2.04	0.08
2022/8/4*	31.1	2.17	1.91	0.26
2022/8/25*	89.4	2.52	1.51	1.01
2022/8/26	11.7	1.62	1.50	0.12
2022/8/27	25.6	1.61	1.19	0.42
2022/8/28*	50.6	1.44	0.59	0.85
*.剔除降雨强度<10 mm/h和地下水位埋深>2 m的数据

下载: 导出CSV
