苏里格地区致密砂岩矿物组成与微观结构及其对水力压裂的潜在影响

李培月; 何晓东; 周长静; 解永刚; 史华

doi:10.16030/j.cnki.issn.1000-3665.202211048

苏里格地区致密砂岩矿物组成与微观结构及其对水力压裂的潜在影响

doi: 10.16030/j.cnki.issn.1000-3665.202211048

李培月^{1, 2, 3,},
何晓东^{1, 2, 3},
周长静^{4, 5},
解永刚^{4, 5},
史华^{4, 5}

1.
长安大学水利与环境学院，陕西西安　710054
2.
旱区地下水文与生态效应教育部重点实验室（长安大学），陕西西安　710054
3.
水利部旱区生态水文与水安全重点实验室（长安大学），陕西西安　710054
4.
低渗透油气田勘探开发国家工程实验室，陕西西安　710018
5.
中国石油长庆油田分公司油气工艺研究院，陕西西安　710018

基金项目: 国家自然科学基金项目（42072286；41761144059）；陕西省科技厅秦创原队伍建设项目（2022KXJ-005）；中国石油科学研究与技术开发项目（2021DJ2015）

详细信息

作者简介:
李培月（1984-），男，博士，教授，博士生导师，主要从事环境水文地球化学方面的教学与科研工作。E-mail：lipy2@163.com；lipy2@163.com

中图分类号: P641.4；P618.13
计量
- 文章访问数: 9677
- HTML全文浏览量: 1626
- PDF下载量: 468
- 被引次数: 0
出版历程
- 收稿日期: 2022-11-15
- 修回日期: 2023-01-08
- 网络出版日期: 2023-03-15
- 刊出日期: 2023-05-15

Mineral compositions and microstructural characteristics of the tight sandstone reservoir in the Sulige area and their potential influence on hydraulic fracturing

LI Peiyue^{1, 2, 3
,},
HE Xiaodong^{1, 2, 3},
ZHOU Changjing^{4, 5},
XIE Yonggang^{4, 5},
SHI Hua^{4, 5}

1.
School of Water and Environment, Chang’an University, Xi’an, Shaanxi　710054, China
2.
Key Laboratory of Subsurface Hydrology and Ecological Effects in Arid Regions of the Ministry of Education(Chang’an University), Xi’an, Shaanxi　710054, China
3.
Key Laboratory of Eco-Hydrology and Water Security in Arid and Semi-arid Regions of the Ministry of Water Resources(Chang’an University), Xi’an, Shaanxi　710054, China
4.
National Engineering Laboratory for Exploration and Development of Low-Permeability Oil & Gas Fields, Xi’an, Shaanxi　710018, China
5.
Oil and Gas Technology Research Institute of Changqing Oilfield Company, PetroChina, Xi’an, Shaanxi,　710018, China

摘要

摘要: 致密砂岩气是重要的非常规天然气资源，致密砂岩储层的矿物组成特征与孔隙微观结构不仅会影响致密储层中天然气的赋存状态，同时也对水力压裂改造效果具有重要影响。然而，有关致密砂岩矿物成分及其微观赋存形态对气井水力压裂潜在影响的研究尚不充分，针对这一问题，文章以鄂尔多斯盆地苏里格地区主开采层——二叠系下石盒子组盒8_下段致密砂岩为研究对象，钻取5口气井岩心样品，利用XRF、XRD、铸体薄片、SEM及EDS能谱等技术系统分析了该段致密砂岩矿物组成、微观形貌、孔隙分布等储层特征。基于分析结果，探讨了上述储层特征因素对水力压裂的潜在影响。研究发现，苏里格地区盒8_下段致密砂岩主要为岩屑砂岩和岩屑石英砂岩，密度介于2.44～2.56 g/cm³之间，孔隙度为7.7%～12.6%，渗透率为0.16～1.42 mD，属于典型的低渗透气藏。矿物成分主要为石英和黏土矿物，而长石矿物和碳酸盐矿物含量极低。其中黏土矿物含量占比为16.5%～47.4%，以高岭石、伊利石和绿泥石为主。高岭石在该区致密砂岩中广泛发育，呈书页状和蠕虫状填充于粒间孔隙及粒表，形成大量高岭石晶间孔。此外，致密砂岩中粒间孔隙、粒内溶孔、粒间裂隙及粒内缝均有发育，为致密砂岩气的赋存提供了良好的储集空间。矿物分析以及压裂液致密砂岩水岩实验结果显示黏土矿物稳定性对于苏里格地区致密砂岩气水力压裂效果至关重要，尤其是易分散运移的高岭石和伊利石矿物。水力压裂前需要对储层矿物成分及地层水成分展开详细研究，选择合适的黏土稳定剂优化水力压裂。
- 致密砂岩 /
- 微观形貌 /
- 黏土矿物 /
- 水力压裂 /
- 苏里格气田
Abstract: Tight sandstone gas is an important unconventional natural gas resource. Mineral characteristics of the tight sandstone not only affect the occurrence of gas, but also have a significant impact on the hydraulic fracturing effectiveness. The potential influence of tight sandstone mineral compositions and microscopic morphology on gas reservoir during hydraulic fracturing was seldom examined. In this study, five tight sandstone gas wells in the Sulige gasfield located in the Ordos Basin were drilled. The core samples of the 8^th formation of the lower member of the Permian Shihezi Group (He 8) were collected. The mineral characteristics, microstructure and pore feature of the tight sandstone are systematically analyzed by using XRF, XRD, casting thin section, SEM and EDS technologies and the potential effects of the above factors on hydraulic fracturing are discussed. The results show that the tight sandstone is mainly composed of lithic sandstone and lithic quartz sandstone. The density of the tight sandstone ranges from 2.44 to 2.56 g/cm³, the porosity from 7.7% to 12.6%, and the permeability from 0.16 to 1.42 mD. The mineral compositions are mainly quartz and clay minerals (16.5%−47.4%), and feldspar and carbonate are absent. Kaolinite, illite and chlorite are the main clay minerals. Kaolinite is widely developed, filling the intergranular pores and surface in the forms of “booklets” and worm-like. The intergranular pores, intragranular solution voids, intergranular and intragranular fractures occur in the tight sandstone, which provide basic reservoir space for natural gas. The results of mineral analysis and fracturing fluid-tight sandstone interactions reveal that the stability of clay minerals, especially kaolinite and illite, are crucial for hydraulic fracturing in the Sulige gasfield. It is necessary to understand the mineral compositions and formation water of the tight reservoir and select the appropriate clay stabilizer to optimize hydraulic fracturing.
- tight sandstone /
- microstructure /
- clay minerals /
- hydraulic fracturing /
- Sulige gasfield

HTML全文

图 1 研究区位置及取样井分布

Figure 1. Location of the study area and samples

下载: 全尺寸图片幻灯片

图 2 致密砂岩显微照片

Figure 2. Micrographs of the tight sandstone

下载: 全尺寸图片幻灯片

图 3 致密砂岩铸体薄片显微照片

Figure 3. Micrographs of the cast thin section of the tight sandstone

下载: 全尺寸图片幻灯片

图 4 典型矿物显微照片与能谱分析

Figure 4. SEM and EDS analyses of the typical minerals

下载: 全尺寸图片幻灯片

图 5 致密砂岩微观孔隙特征

Figure 5. Microscopic pore characteristics of the tight sandstone

下载: 全尺寸图片幻灯片

图 6 压裂液处理后黏土矿物微观形貌

Figure 6. Microstructure of the clay minerals after fracturing fluid-tight sandstone interactions

下载: 全尺寸图片幻灯片

表 1 储层岩心主要元素含量

Table 1. Main elements of the reservoir core /（mg·kg⁻¹）

样品编号	Zr	Sr	Rb	Zn	Fe	Mn	Cr	V	Ti	Ca	K
桃10	183.6	71.95	51.43	44.48	24028	216.1	< LOD	50.81	2384	3261	15949
召42	426.0	112.30	97.93	42.34	31273	350.0	33.76	114.6	7667	2316	32037
统98	218.9	84.50	58.42	33.52	19717	397.2	< LOD	< LOD	3607	14964	21756
召60	131.8	82.16	29.92	39.58	16930	1429.0	< LOD	36.85	1812	50787	9202
召62	279.8	128.40	103.00	71.20	29066	272.1	< LOD	104.7	4542	5527	39314
注：<LOD表示低于检出限。

下载: 导出CSV

表 2 储层岩心矿物组成

Table 2. Mineral compositions of the reservoir core /（wt%）

样品编号	石英	斜长石	钾长石	方解石	伊利石	绿泥石+高岭石	赤铁矿	方沸石
桃10	74.6	−	−	0.4	4.2	19.8	1.0	−
召42	65.6	0.2	0.2	0.4	9.8	22.9	0.9	−
统98	81.6	−	−	1.0	5.6	10.9	0.9	−
召60	45.9	−	−	18.0	3.9	31.8	−	0.4
召62	51.5	−	−	0.4	27.3	20.1	0.7	−

下载: 导出CSV

参考文献(37)

[1]	邹才能, 陶士振, 侯连华. 非常规油气地质[M]. 2版. 北京: 地质出版社, 2013 ZOU Caineng, TAO Shizhen, HOU Lianhua. Unconventional petroleum geology[M]. 2nd ed. Beijing: Geological Publishing House, 2013. （in Chinese）
[2]	US Energy Information Administration. International energy outlook 2021[R]. Washington: Center for Strategic and International Studies, 2021. https://www.eia.gov/outlooks/ieo.
[3]	李鹭光. 中国天然气工业发展回顾与前景展望[J]. 天然气工业,2021,41(8):1 − 11. [LI Luguang. Development of natural gas industry in China:Review and prospect[J]. Natural Gas Industry,2021,41(8):1 − 11. (in Chinese with English abstract) doi: 10.3787/j.issn.1000-0976.2021.08.001
[4]	贾爱林,位云生,郭智,等. 中国致密砂岩气开发现状与前景展望[J]. 天然气工业,2022,42(1):83 − 92. [JIA Ailin,WEI Yunsheng,GUO Zhi,et al. Development status and prospect of tight sandstone gas in China[J]. Natural Gas Industry,2022,42(1):83 − 92. (in Chinese with English abstract) doi: 10.3787/j.issn.1000-0976.2022.01.008
[5]	孙龙德,邹才能,贾爱林,等. 中国致密油气发展特征与方向[J]. 石油勘探与开发,2019,46(6):1015 − 1026. [SUN Longde,ZOU Caineng,JIA Ailin,et al. Development characteristics and orientation of tight oil and gas in China[J]. Petroleum Exploration and Development,2019,46(6):1015 − 1026. (in Chinese with English abstract) doi: 10.11698/PED.2019.06.01
[6]	BIRKLE P,MAKECHNIE G K. Geochemical cycle of hydraulic fracturing fluids:Implications for fracture functionality and frac job efficiency in tight sandstone[J]. Journal of Petroleum Science and Engineering,2022,208:109596. doi: 10.1016/j.petrol.2021.109596
[7]	WANG Yifei,LIU Huaishan,LI Sanzhong,et al. Potentials of low permeability gas in intracratonic basin:Insights from sedimentary facies of the Shan1 member in the Su6-Zhao42 Block of the Sulige gas field,Ordos Basin[J]. Geological Journal,2018,53:201 − 211. doi: 10.1002/gj.3056
[8]	刘毅,李建奇,冯强汉,等. 苏里格气田苏48区块石盒子组8段气水识别方法研究[J]. 石油天然气学报,2014,36(9):84 − 87. [LIU Yi,LI Jianqi,FENG Qianghan,et al. Gas and water identification method in block Su 48 in the 8^th member of Shihezi formation in Sulige gasfield[J]. Journal of Oil and Gas Technology,2014,36(9):84 − 87. (in Chinese) doi: 10.3969/j.issn.1000-9752.2014.09.017
[9]	郭艳琴,何子琼,郭彬程,等. 苏里格气田东南部盒8段致密砂岩储层特征及评价[J]. 岩性油气藏,2019,31(5):1 − 11. [GUO Yanqin,HE Ziqiong,GUO Bincheng,et al. Reservoir characteristics and evaluation of tight sandstone of He₈ member in southeastern Sulige Gas Field,Ordos Basin[J]. Lithologic Reservoirs,2019,31(5):1 − 11. (in Chinese with English abstract) doi: 10.12108/yxyqc.20190501
[10]	杨仁超,董亮,张吉,等. 苏里格气田西区地层水成因、分布规律与控制因素[J]. 沉积学报,2022,40(1):267 − 280. [YANG Renchao,DONG Liang,ZHANG Ji,et al. Origin,distribution and controlling factors of stratigraphic water in the western Sulige gas field[J]. Acta Sedimentologica Sinica,2022,40(1):267 − 280. (in Chinese with English abstract)
[11]	FAN Aiping,YANG Renchao,LENHARDT N,et al. Cementation and porosity evolution of tight sandstone reservoirs in the Permian Sulige gas field,Ordos Basin (central China)[J]. Marine and Petroleum Geology,2019,103:276 − 293. doi: 10.1016/j.marpetgeo.2019.02.010
[12]	WU Heyuan,ZHAO Jingzhou,WU Weitao,et al. Formation and diagenetic characteristics of tight sandstones in closed to semi-closed systems:Typical example from the Permian Sulige gas field[J]. Journal of Petroleum Science and Engineering,2021,199:108248. doi: 10.1016/j.petrol.2020.108248
[13]	邹才能,郭建林,贾爱林,等. 中国大气田科学开发的内涵[J]. 天然气工业,2020,40(3):1 − 12. [ZOU Caineng,GUO Jianlin,JIA Ailin,et al. Connotation of scientific development for giant gas fields in China[J]. Natural Gas Industry,2020,40(3):1 − 12. (in Chinese with English abstract) doi: 10.3787/j.issn.1000-0976.2020.03.001
[14]	张吉, 余浩杰, 马志欣, 等. 苏里格致密砂岩气储层定量表征[M]. 北京: 石油工业出版社, 2019 ZHANG Ji, YU Haojie, MA Zhixin, et al. Quantitative characterization of Sulige tight sandstone gas reservoir[M]. Beijing: Petroleum Industry Press, 2019. （in Chinese）
[15]	ZOU Caineng,TAO Shizhen,HAN Wenxue,et al. Geological and geochemical characteristics and exploration prospect of coal-derived tight sandstone gas in China:Case study of the Ordos,Sichuan,and Tarim Basins[J]. Acta Geologica Sinica - English Edition,2018,92(4):1609 − 1626. doi: 10.1111/1755-6724.13647
[16]	WU Weitao,ZHAO Jingzhou,WEI Xinshan,et al. Evaluation of gas-rich “sweet-spot” and controlling factors of gas-water distribution in tight sandstone gas provinces:An example from the Permian He8 member in Sulige gas province,central ordos basin,northern China[J]. Journal of Asian Earth Sciences,2022,227:105098. doi: 10.1016/j.jseaes.2022.105098
[17]	魏新善,胡爱平,赵会涛,等. 致密砂岩气地质认识新进展[J]. 岩性油气藏,2017,29(1):11 − 20. [WEI Xinshan,HU Aiping,ZHAO Huitao,et al. New geological understanding of tight sandstone gas[J]. Lithologic Reservoirs,2017,29(1):11 − 20. (in Chinese with English abstract) doi: 10.3969/j.issn.1673-8926.2017.01.002
[18]	HUI Wei,WANG Yueshe,REN Dazhong,et al. Effects of pore structures on the movable fluid saturation in tight sandstones:A He₈ formation example in Sulige Gasfield,Ordos Basin,China[J]. Journal of Petroleum Science and Engineering,2020,192:107295. doi: 10.1016/j.petrol.2020.107295
[19]	窦伟坦,刘新社,王涛. 鄂尔多斯盆地苏里格气田地层水成因及气水分布规律[J]. 石油学报,2010,31(5):767 − 773. [DOU Weitan,LIU Xinshe,WANG Tao. The origin of formation water and the regularity of gas and water distribution for the Sulige gas field,Ordos Basin[J]. Acta Petrolei Sinica,2010,31(5):767 − 773. (in Chinese with English abstract) doi: 10.7623/syxb201005011
[20]	苏小四,吴春勇,董维红,等. 鄂尔多斯沙漠高原白垩系地下水锶同位素的演化机理[J]. 成都理工大学学报(自然科学版),2011,38(3):348 − 358. [SU Xiaosi,WU Chunyong,DONG Weihong,et al. Strontium isotope evolution mechanism of the Cretaceous groundwater in Ordos Desert Plateau[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2011,38(3):348 − 358. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-9727.2011.03.017
[21]	杨涵菲,赵艳,崔巧玉,等. 基于XRF岩芯扫描的Rb/Sr比值的古气候意义探讨—以青藏高原东部若尔盖盆地为例[J]. 中国科学:地球科学,2021,51(1):73 − 91. [YANG Hanfei,ZHAO Yan,CUI Qiaoyu,et al. Paleoclimatic indication of X-ray fluorescence core-scanned Rb/Sr ratios:A case study in the Zoige Basin in the eastern Tibetan Plateau[J]. Science China Earth Sciences,2021,51(1):73 − 91. (in Chinese with English abstract)
[22]	陈敬安,曾艳,王敬富,等. 湖泊沉积物不同赋存状态Rb、Sr地球化学记录研究[J]. 矿物岩石地球化学通报,2013,32(4):408 − 417. [CHEN Jing’an,ZENG Yan,WANG Jingfu,et al. The geochemical records of Rb and Sr of different forms in lake sediments[J]. Bulletion of Mineralogy,Petrology and Geochemistry,2013,32(4):408 − 417. (in Chinese with English abstract) doi: 10.3969/j.issn.1007-2802.2013.04.004
[23]	HE Xiaodong,LI Peiyue,SHI Hua,et al. Identifying strontium sources of flowback fluid and groundwater pollution using ⁸⁷Sr/⁸⁶Sr and geochemical model in Sulige gasfield,China[J]. Chemosphere,2022,306:135594. doi: 10.1016/j.chemosphere.2022.135594
[24]	BELYADI H, FATHI E, BELYAD F. Hydraulic fracturing in unconventional reservoirs: Theories, operations, and economic analysis[M]. 2nd ed. Cambridge: Gulf Professional Publishing, Elsevier, 2019.
[25]	任大忠,周兆华,梁睿翔,等. 致密砂岩气藏黏土矿物特征及其对储层性质的影响:以鄂尔多斯盆地苏里格气田为例[J]. 岩性油气藏,2019,31(4):42 − 53. [REN Dazhong,ZHOU Zhaohua,LIANG Ruixiang,et al. Characteristics of clay minerals and its impacts on reservoir quality of tight sandstone gas reservoir:A case from Sulige Gas Field,Ordos Basin[J]. Lithologic Reservoirs,2019,31(4):42 − 53. (in Chinese with English abstract) doi: 10.12108/yxyqc.20190405
[26]	周康,刘佳庆,段国英,等. 吴起地区长61油层黏土矿物对油层低电阻率化的影响[J]. 岩性油气藏,2012,24(2):26 − 30. [ZHOU Kang,LIU Jiaqing,DUAN Guoying,et al. Effect of clay minerals on low resistivity of Chang 61 reservoir in Wuqi area[J]. Lithologic Reservoirs,2012,24(2):26 − 30. (in Chinese with English abstract) doi: 10.3969/j.issn.1673-8926.2012.02.006
[27]	CIVAN F. Reservoir formation damage: Fundamentals, modeling, assessment, and mitigation[M]. 3rd ed. Waltham: Elsevier, 2015.
[28]	李阳,李树同,牟炜卫,等. 鄂尔多斯盆地姬塬地区长6段致密砂岩中黏土矿物对储层物性的影响[J]. 天然气地球科学,2017,28(7):1043 − 1053. [LI Yang,LI Shutong,MOU Weiwei,et al. Influences of clay minerals on physical properties of Chang 6 tight sandstone reservoir in Jiyuan area,Ordos Basin[J]. Natural Gas Geoscience,2017,28(7):1043 − 1053. (in Chinese with English abstract)
[29]	WANG Ren,SHI Wanzhong,XIE Xiangyang,et al. Clay mineral content,type,and their effects on pore throat structure and reservoir properties:Insight from the Permian tight sandstones in the Hangjinqi area,north Ordos Basin,China[J]. Marine and Petroleum Geology,2020,115:104281. doi: 10.1016/j.marpetgeo.2020.104281
[30]	KHAN H J,SPIELMAN-SUN E,JEW A D,et al. A critical review of the physicochemical impacts of water chemistry on shale in hydraulic fracturing systems[J]. Environmental Science & Technology,2021,55(3):1377 − 1394.
[31]	HUANG Tianming,LI Zhenbin,MAYER B,et al. Identification of geochemical processes during hydraulic fracturing of a shale gas reservoir:A controlled field and laboratory water-rock interaction experiment[J]. Geophysical Research Letters,2020,47(20):e2020GL090420.
[32]	JACOBS T. Improving shale production through flowback analysis[J]. Journal of Petroleum Technology,2015,67(12):37 − 42. doi: 10.2118/1215-0037-JPT
[33]	STEUDEL A,BATENBURG L F,FISCHER H R,et al. Alteration of non-swelling clay minerals and magadiite by acid activation[J]. Applied Clay Science,2009,44(1/2):95 − 104.
[34]	TANG Hongming,TANG Haoxuan,HE Jiang,et al. Damage mechanism of water-based fracturing fluid to tight sandstone gas reservoirs:Improvement of the evaluation measurement for properties of water-based fracturing fluid:SY/T 5107—2016[J]. Natural Gas Industry B,2021,8(2):163 − 172. doi: 10.1016/j.ngib.2020.09.016
[35]	QI Aojiang, QIAN Pinshu, HUANG Hai, et al. Research on the characteristics of microscopic damage to different pore types by slippery water fracturing fluid in the Chang member tight sandstone reservoir, Ordos Basin, NW China[J]. Geofluids, 2021: 1 − 8.
[36]	邹才能. 非常规油气勘探开发[M]. 北京: 石油工业出版社, 2019 ZOU Caineng. Unconventional oil & gas exploration and development[M]. Beijing: Petroleum Industry Press, 2019. （in Chinese）
[37]	HE Xiaodong,LI Peiyue,NING Jing,et al. Geochemical processes during hydraulic fracturing in a tight sandstone reservoir revealed by field and laboratory experiments[J]. Journal of Hydrology,2022,612:128292. doi: 10.1016/j.jhydrol.2022.128292
