保定平原地下水均衡要素变化解析

井江楠 王文科 段磊 马嘉骏 马稚桐 石涵月

井江楠,王文科,段磊,等. 保定平原地下水均衡要素变化解析[J]. 水文地质工程地质,2023,50(0): 1-13 doi:  10.16030/j.cnki.issn.1000-3665.202208083
引用本文: 井江楠,王文科,段磊,等. 保定平原地下水均衡要素变化解析[J]. 水文地质工程地质,2023,50(0): 1-13 doi:  10.16030/j.cnki.issn.1000-3665.202208083
JING Jiangnan, WANG Wenke, DUAN Lei, et al. An analysis of the changes in groundwater balance elements of the Baoding Plain[J]. Hydrogeology & Engineering Geology, 2023, 50(0): 1-13 doi:  10.16030/j.cnki.issn.1000-3665.202208083
Citation: JING Jiangnan, WANG Wenke, DUAN Lei, et al. An analysis of the changes in groundwater balance elements of the Baoding Plain[J]. Hydrogeology & Engineering Geology, 2023, 50(0): 1-13 doi:  10.16030/j.cnki.issn.1000-3665.202208083

保定平原地下水均衡要素变化解析

doi: 10.16030/j.cnki.issn.1000-3665.202208083
基金项目: 国家重点研发计划项目(2018YFC0406504);国家自然科学重点基金项目(42130710)
详细信息
    作者简介:

    井江楠(1998-),女,硕士研究生,主要从事旱区地下水文过程与生态效应研究。E-mail:2020129007@chd.edu.cn

    通讯作者:

    王文科(1962-),男,博士,教授,博士生导师,主要从事旱区地下水文过程与生态效应研究。E-mail:wenkew@chd.edu.cn

  • 中图分类号: P641.8

An analysis of the changes in groundwater balance elements of the Baoding Plain

  • 摘要: 随着南水北调工程的实施及地下水压采工作的落实,华北平原局部地下水水位逐步回升,然而地下水均衡要素变化趋势及对生态环境的影响缺乏系统研究。以华北平原典型区域南水北调受水区保定平原为例,采用水均衡法计算地下水补给和排泄项,应用因子分析法分析1975—2019年地下水均衡要素变化的原因,根据最优开采系数法计算地下水可采资源和压采资源量,以此调控保定平原地下水资源的开发利用。结果表明:近40年来,保定平原地下水补给项小于排泄项,呈负均衡状态,主要发生变化的地下水均衡要素有渠灌入渗、渠系渗漏、井灌回归、河道渗漏、降雨入渗和人工开采;影响地下水均衡要素变化的主要因子是人类活动,贡献率为77.2%;地下水补排失衡减缓后地下水水位埋深增幅变小、地下水水位降落漏斗面积逐渐减少、白洋淀湿地面积逐步恢复;确定了保定平原地下水资源的最优开采系数为0.64,地下水可开采资源量的范围为8.89×108 ~11.35×108 m3/a,压采量为2.68×108~5.14×108 m3/a。研究成果为同类地下水开采利用提供了技术指导,也为雄安新区建设提供了地下水生态环境保障。
  • 图  1  研究区水文地质分区及河流水系图

    Figure  1.  Hydrogeological zoning and river systems in the study area

    图  2  典型剖面岩性变化图(Ⅰ-Ⅰ’)

    Figure  2.  Lithology in the typical proflie

    图  3  保定平原1975—1985年地下水水位埋深变化

    Figure  3.  Variation of groundwater levels in the Baoding Plain from 1975 to 1985

    图  4  保定平原1975、2006、2011、2019年地下水水位埋深空间变化图

    Figure  4.  Spatial variation of groundwater levels in the Baoding Plain in 1975, 2006, 2011 and 2019

    图  5  白洋淀湖泊湿地面积水位变化图

    Figure  5.  Water level change of the Baiyangdian Lake wetland area

    图  6  1980—2019年研究区内渠首引水量变化

    Figure  6.  Changes of water diversion volume of the canal head in the study area from 1975 to 2019

    图  7  1975—2019年研究区内不同水文站径流量变化

    Figure  7.  Runoff variations of different hydrological stations in the study area from 1975 to 2019

    图  8  研究区内耕地面积变化和节水灌溉面积变化图

    Figure  8.  Changes in arable land area and water-saving irrigation area in the study area

    图  9  1975—2019年研究区内农业灌溉地下水开采量变化图

    Figure  9.  Changes in groundwater extraction for agricultural irrigation in the study area from 1975 to 2019

    图  10  1975—2019年研究区降雨量变化图

    Figure  10.  Rainfall variation of the study area from 1975 to 2019

    图  11  研究区内各行政区地下水压采范围图

    Figure  11.  Groundwater compression exploitation scope of each administrative region in the study area

    表  1  研究区浅层地下水均衡要素及其占比

    Table  1.   Shallow groundwater balance elements and percentage in the study area

    均衡要素1975年1985年2006年2011年2019年
    数量
    /(108 m3·a−1
    占比数量
    /(108 m3·a−1
    占比数量
    /(108 m3·a−1
    占比数量
    /(108 m3·a−1
    占比数量
    /(108 m3·a−1
    占比
    补给项降水入渗14.6672.86%16.9578.69%9.1367.34%13.5669.96%10.8376.32%
    井灌回归2.4912.38%2.069.56%1.6612.22%1.598.22%0.473.31%
    渠灌入渗0.180.89%0.150.70%0.221.62%0.100.49%0.020.14%
    渠系渗漏0.462.29%0.391.81%0.554.03%0.261.32%0.050.35%
    河道渗漏0.572.83%0.452.09%0.423.10%1.799.26%0.53.52%
    白洋淀渗漏0.221.09%0.000.00%0.040.31%0.010.06%0.251.76%
    侧向流入1.547.65%1.547.15%1.5411.37%2.0710.69%2.0714.59%
    合计20.12100%21.54100%10.17100%19.38100%14.19100%
    排泄项侧向流出0.351.65%0.351.28%1.615.13%1.355.18%1.358.78%
    人工开采20.7097.37%27.1098.02%29.7494.87%24.7194.82%14.0391.22%
    潜水蒸发0.210.99%0.190.70%//////
    合计21.26100%27.65100%31.35100%26.06100%15.38100%
    地下水储存量的变化量−1.14−6.11−17.19−6.68−1.19
    下载: 导出CSV

    表  2  研究区浅层地下水均衡要素变化

    Table  2.   Changes of groundwater balance elements of the shallow groundwater in the study area

    均衡要素变幅
    1975—19851985—20062006—20112011—2019
    补给项降水入渗15.62%−46.14%48.53%−20.14%
    井灌回归−17.27%−19.54%−3.86%−70.50%
    渠灌入渗−16.67%46.67%−56.73%−78.99%
    渠系渗漏−15.22%40.00%−53.21%−80.43%
    河道渗漏−21.05%−6.67%327.34%−72.14%
    白洋淀渗漏−100.00%/−72.00%2000.84%
    侧向流入0.00%0.13%34.36%−0.09%
    排泄项侧向流出1.29%353.99%−16.06%−0.07%
    人工开采30.92%9.74%−16.91%−43.22%
    潜水蒸发−7.90%−100.00%//
    下载: 导出CSV

    表  3  补给项主要驱动因子特征

    Table  3.   Initial eigenvalue, contribution rate and cumulative contribution rate of the main driving factors of recharge items

    成分初始特征值贡献率/%累积贡献率/%
    13.81854.5454.54
    21.58722.6677.20
    31.16216.6093.80
    下载: 导出CSV

    表  4  补给项主要驱动因子载荷矩阵

    Table  4.   Load matrix of the main driving factors of recharge items

    均衡要素成分
    123
    降水入渗0.348−0.0640.935
    井灌回归0.906−0.0110.295
    渠灌入渗0.9570.063−0.309
    渠系渗漏0.9570.068−0.277
    河道渗漏−0.1310.940−0.039
    白洋淀渗漏−0.448−0.751−0.127
    侧向流入−0.9190.3550.105
    下载: 导出CSV
  • [1] WADA Y,VAN BEEK L P H,VAN KEMPEN C M,et al. Global depletion of groundwater resources[J]. Geophysical Research Letters,2010,37(20):1 − 5.
    [2] TAYLOR R G,SCANLON B,DÖLL P,et al. Ground water and climate change[J]. Nature Climate Change,2013,3(4):322 − 329. doi:  10.1038/nclimate1744
    [3] SIEBERT S, BURKE J, FAURES J M, et al. Groundwater use for irrigation – a global inventory[J]. Hydrology and Earth System Sciences, 14(10): 1863-1880.
    [4] ALLEY W M,HEALY R W,LABAUGH J W,et al. Flow and storage in groundwater systems[J]. Science,2002,296(5575):1985 − 1990. doi:  10.1126/science.1067123
    [5] 陈飞,徐翔宇,羊艳,等. 中国地下水资源演变趋势及影响因素分析[J]. 水科学进展,2020,31(6):811 − 819. [CHEN Fei,XU Xiangyu,YANG Yan,et al. Investigation on the evolution trends and influencing factors of groundwater resources in China[J]. Advances in Water Science,2020,31(6):811 − 819. (in Chinese with English abstract)
    [6] 刘昶,郑明霞,孙源媛,等. 河道硬化对傍河地下水源补给结构及范围的影响[J]. 环境科学研究,2020,33(12):2820 − 2828. [LIU Chang,ZHENG Mingxia,SUN Yuanyuan,et al. Effects of river hardening on recharging structure and range of riverside groundwater source field[J]. Research of Environmental Sciences,2020,33(12):2820 − 2828. (in Chinese with English abstract)
    [7] 柴政,玉米提·哈力克,苟新华,等. 新疆柴窝堡水源地地下水超采引发的环境问题[J]. 水土保持研究,2008,15(5):132 − 135. [CHAI Zheng,UMUT Halik,GOU Xinhua,et al. Environmental problems caused by excessive exploitation of groundwater at chaiwopu source in Xinjiang[J]. Research of Soil and Water Conservation,2008,15(5):132 − 135. (in Chinese with English abstract)
    [8] 郭晓东,王晓光,刘强,等. 松花江—辽河流域地下水资源及其生态环境问题[J]. 中国地质,2021,48(4):1062 − 1074. [GUO Xiaodong,WANG Xiaoguang,LIU Qiang,et al. Groundwater resources and ecological environment in Songhua River-Liaohe River Basin[J]. Geology in China,2021,48(4):1062 − 1074. (in Chinese with English abstract)
    [9] WANG Wenke,ZHANG Zaiyong,DUAN Lei,et al. Response of the groundwater system in the Guanzhong Basin (central China) to climate change and human activities[J]. Hydrogeology Journal,2018,26(5):1429 − 1441. doi:  10.1007/s10040-018-1757-7
    [10] 管春兴,张虹波,王战,等. 玛纳斯河流域山前平原区地下水资源动态变化分析[J]. 水利水电技术,2019,50(3):1 − 9. [GUAN Chunxing,ZHANG Hongbo,WANG Zhan,et al. Dynamic change analysis on groundwater resources in piedmont plain of Manas River Basin[J]. Water Resources and Hydropower Engineering,2019,50(3):1 − 9. (in Chinese with English abstract)
    [11] 丁启振,周金龙,杜明亮,等. 新疆石河子-昌吉地区2016―2020年地下水位动态特征分析[J]. 灌溉排水学报,2022,41(2):109 − 117. [DING Qizhen,ZHOU Jinlong,DU Mingliang,et al. Spatiotemporal variation of groundwater table from 2016 to 2020 in Shihezi-Changji of Xinjiang[J]. Journal of Irrigation and Drainage,2022,41(2):109 − 117. (in Chinese with English abstract)
    [12] 霍世璐,王文科,段磊,等. 霍城县地下水资源构成变化及驱动力分析[J]. 水文地质工程地质,2020,47(2):51 − 59. [HUO Shilu,WANG Wenke,DUAN Lei,et al. An analysis of groundwater resources composition and driving force in Huocheng County[J]. Hydrogeology & Engineering Geology,2020,47(2):51 − 59. (in Chinese with English abstract)
    [13] 费宇红,张兆吉,张凤娥,等. 华北平原地下水水位动态变化影响因素分析[J]. 河海大学学报(自然科学版),2005,33(5):538 − 541. [FEI Yuhong,ZHANG Zhaoji,ZHANG Fenge,et al. Factors affecting dynamic variation of groundwater level in North China Plain[J]. Journal of Hohai University(Natural Sciences),2005,33(5):538 − 541. (in Chinese with English abstract)
    [14] 张光辉,费宇红,刘春华,等. 华北平原灌溉用水强度与地下水承载力适应性状况[J]. 农业工程学报,2013,29(1):1 − 10. [ZHANG Guanghui,FEI Yuhong,LIU Chunhua,et al. Adaptation between irrigation intensity and groundwater carrying capacity in North China Plain[J]. Transactions of the Chinese Society of Agricultural Engineering,2013,29(1):1 − 10. (in Chinese with English abstract)
    [15] 吴彬,杜明亮,穆振侠,等. 1956—2016年新疆平原区地下水资源量变化及其影响因素分析[J]. 水科学进展,2021,32(5):659 − 669. [WU Bin,DU Mingliang,MU Zhenxia,et al. Analysis on the variation of groundwater resources and influencing factors in Xinjiang plain area from 1956 to 2016[J]. Advances in Water Science,2021,32(5):659 − 669. (in Chinese with English abstract)
    [16] 沈蕊芯,吕树萍,杜明亮,等. 新疆奎屯河流域平原区地下水资源量演变情势[J]. 干旱区研究,2020,37(4):839 − 846. [SHEN Ruixin,LYU Shuping,DU Mingliang,et al. Analysis of groundwater resources evolution in the Plains of Kuytun River Basin[J]. Arid Zone Research,2020,37(4):839 − 846. (in Chinese with English abstract)
    [17] 张文鸽,侯胜玲,殷会娟. 内蒙古河套灌区地下水埋深时空变化及其驱动因素[J]. 节水灌溉,2020(7):36 − 40. [ZHANG Wenge,HOU Shengling,YIN Huijuan. Spatial and temporal variation of groundwater depth and its driving factors in Hetao irrigation district of Inner Mongolia[J]. Water Saving Irrigation,2020(7):36 − 40. (in Chinese with English abstract)
    [18] 杨会峰,曹文庚,支传顺,等. 近40年来华北平原地下水位演变研究及其超采治理建议[J]. 中国地质,2021,48(4):1142 − 1155. [YANG Huifeng,CAO Wengeng,ZHI Chuanshun,et al. Evolution of groundwater level in the North China Plain in the past 40 years and suggestions on its overexploitation treatment[J]. Geology in China,2021,48(4):1142 − 1155. (in Chinese with English abstract)
    [19] WANG Shiqin,SONG Xianfang,WANG Qinxue,et al. Shallow groundwater dynamics in North China Plain[J]. Journal of Geographical Sciences,2009,19(2):175 − 188. doi:  10.1007/s11442-009-0175-0
    [20] 王仕琴,宋献方,王勤学,等. 华北平原地下水位微动态变化周期特征分析[J]. 水文地质工程地质,2014,41(3):6 − 12. [WANG Shiqin,SONG Xianfang,WANG Qinxue,et al. An analysis of period features of groundwater micro-dynamics in the North China Plain[J]. Hydrogeology & Engineering Geology,2014,41(3):6 − 12. (in Chinese with English abstract)
    [21] 郭海朋,李文鹏,王丽亚,等. 华北平原地下水位驱动下的地面沉降现状与研究展望[J]. 水文地质工程地质,2021,48(3):162 − 171. [GUO Haipeng,LI Wenpeng,WANG Liya,et al. Present situation and research prospects of the land subsidence driven by groundwater levels in the North China Plain[J]. Hydrogeology & Engineering Geology,2021,48(3):162 − 171. (in Chinese with English abstract)
    [22] 赵玉峰,罗专溪,于亚军,等. 京津冀西北典型区域地下水位时空演变及驱动因素[J]. 自然资源学报,2020,35(6):1301 − 1313. [ZHAO Yufeng,LUO Zhuanxi,YU Yajun,et al. Spatio-temporal changes of groundwater level and its driving factors in a typical region of Beijing-Tianjin-Hebei region,China[J]. Journal of Natural Resources,2020,35(6):1301 − 1313. (in Chinese with English abstract) doi:  10.31497/zrzyxb.20200604
    [23] 张福洋,程伍群,冉红达. 保定市平原区地下水位变化规律及影响因素分析[J]. 水电能源科学,2017,35(8):128 − 132. [ZHANG Fuyang,CHENG Wuqun,RAN Hongda. Variation of groundwater level and its influencing factors analysis in plain area of Baoding city[J]. Water Resources and Power,2017,35(8):128 − 132. (in Chinese with English abstract)
    [24] 赵瑞科. 基于生态约束的保定市平原区地下水资源承载力研究[D]. 郑州: 华北水利水电大学, 2018

    ZHAO Ruike. Study on groundwater resource carrying capacity in plain area of Baoding city based on ecological constraints[D]. Zhengzhou: North China University of Water Resources and Electric Power, 2018. (in Chinese with English abstract)
    [25] 靳博文,王文科,段磊,等. 保定平原区地下水生态水位阈值的探讨[J]. 水文地质工程地质,2022,49(5):166 − 175. [JIN Bowen,WANG Wenke,DUAN Lei,et al. Discussion on ecological water level threshold of groundwater in Baoding Plain area[J]. Hydrogeology & Engineering Geology,2022,49(5):166 − 175. (in Chinese with English abstract)
    [26] 田晓华, 冯创业, 张增勤, 等. 京津冀协同发展(保定市平原区)地质环境保障调查评价[R]. 石家庄: 河北省地矿局水文地质勘察院, 2017

    TIAN Xiaohua, FENG Chuangye, ZHANG Zengqin, et al. Investigation and evaluation of geological environment guarantee for the coordinated development of Beijing, Tianjin and Hebei (plain area of Baoding City)[R]. Shijiazhuang: Hydrogeological Survey Institute of Hebei Bureau of Geology and Mineral Resources, 2017. (in Chinese)
    [27] 孟素花,费宇红,张兆吉,等. 50年来华北平原降水入渗补给量时空分布特征研究[J]. 地球科学进展,2013,28(8):923 − 929. [MENG Suhua,FEI Yuhong,ZHANG Zhaoji,et al. Research on spatial and temporal distribution of the precipitation infiltration amount over the past 50 years in North China plain[J]. Advances in Earth Science,2013,28(8):923 − 929. (in Chinese with English abstract)
    [28] 潘恒健. 小清河济南段水质主因子分析[J]. 济南大学学报(自然科学版),2008,22(1):107 − 109. [PAN Hengjian. Characteristics of water quality by principal factor analysis[J]. Journal of University of Jinan (Science and Technology),2008,22(1):107 − 109. (in Chinese with English abstract) doi:  10.3969/j.issn.1671-3559.2008.01.028
    [29] 梁秀娟, 迟宝明, 王文科, 等. 专门水文地质学[M]. 北京: 科学出版社, 2016

    LIANG Xiujunan, CHI Baoming, WANG Wenke, et al. Special hydrogeology[M]. Beijing: Science Press, 2016. (in Chinese)
    [30] 李苗,严思睿,刘强,等. 白洋淀流域径流过程对极端气象干旱的响应分析[J]. 环境工程,2020,38(10):14 − 20. [LI Miao,YAN Sirui,LIU Qiang,et al. Analysis on streamflow processes response to extreme meteorological drought in the Baiyangdian Basin,China[J]. Environmental Engineering,2020,38(10):14 − 20. (in Chinese with English abstract)
    [31] 徐俏,程伍群,孙童,等. 气候因素对白洋淀上游主要河流径流的影响[J]. 河北农业大学学报,2019,42(2):110 − 115. [XU Qiao,CHENG Wuqun,SUN Tong,et al. The influence of climate factors on runoff of major rivers in upper reaches of Baiyangdian Lake[J]. Journal of Hebei Agricultural University,2019,42(2):110 − 115. (in Chinese with English abstract)
    [32] 王政友. 降水入渗补给地下水滞后时间分析探讨[J]. 水文,2011,31(2):42 − 45. [WANG Zhengyou. Discussion on lag time of rainfall penetration recharge to groundwater[J]. Journal of China Hydrology,2011,31(2):42 − 45. (in Chinese with English abstract)
    [33] LI Xi,YAN Li,LU Lijun,et al. Adjacent-track InSAR processing for large-scale land subsidence monitoring in the Hebei plain[J]. Remote Sensing,2021,13(4):795. doi:  10.3390/rs13040795
    [34] FEI Yuhong, ZHANG Zhaoji, QIAN Yong, et al. Assessment on leading factors for dropping of shallow ground water level[C]//2011 International Symposium on Water Resource and Environmental Protection. May 20-22, 2011, Xi’an. IEEE, 2011: 227 − 232.
    [35] 赖冬蓉,陈益平,秦欢欢,等. 变化环境对华北平原地下水可持续利用的影响研究[J]. 水资源与水工程学报,2021,32(5):48 − 55. [LAI Dongrong,CHEN Yiping,QIN Huanhuan,et al. Impacts of changing environment on sustainable utilization of groundwater in the North China Plain[J]. Journal of Water Resources and Water Engineering,2021,32(5):48 − 55. (in Chinese with English abstract)
    [36] 费宇红,张兆吉,张凤娥,等. 气候变化和人类活动对华北平原水资源影响分析[J]. 地球学报,2007,28(6):567 − 571. [FEI Yuhong,ZHANG Zhaoji,ZHANG Feng'e,et al. An analysis of the influence of human activity and climate changeon water resources of the North China plain[J]. Acta Geoscientica Sinica,2007,28(6):567 − 571. (in Chinese with English abstract) doi:  10.3321/j.issn:1006-3021.2007.06.009
    [37] ZHUANG Changwei,OUYANG Zhiyun,XU Weihua,et al. Impacts of human activities on the hydrology of Baiyangdian Lake,China[J]. Environmental Earth Sciences,2011,62(7):1343 − 1350. doi:  10.1007/s12665-010-0620-5
    [38] 王朝华,王子璐,乔光建. 跨流域调水对恢复白洋淀生态环境重要性分析[J]. 南水北调与水利科技,2011,9(3):138 − 141. [WANG Zhaohua,WANG Zilu,QIAO Guangjian. Analysis of importance of inter-basin water diversion to restoration of ecological environment of Baiyangdian Lake[J]. South-to-North Water Transfers and Water Science & Technology,2011,9(3):138 − 141. (in Chinese with English abstract)
    [39] HU Shanshan,LIU Changming,ZHENG Hongxing,et al. Assessing the impacts of climate variability and human activities on streamflow in the water source area of Baiyangdian Lake[J]. Journal of Geographical Sciences,2012,22(5):895 − 905. doi:  10.1007/s11442-012-0971-9
    [40] MOIWO J P,YANG Yonghui,LI Huilong,et al. Impact of water resource exploitation on the hydrology and water storage in Baiyangdian Lake[J]. Hydrological Processes,2010,24(21):3026 − 3039. doi:  10.1002/hyp.7716
    [41] 陈晓磊, 王慧群, 陈萌等. 国务院政策例行吹风会聚焦《地下水管理条例》[N]. 中国水利报, 2021-11-23(002)

    CHEN Xiaolei, WANG Huiqun, CHEN Meng, et al. State Council Policy Briefing Focuses on Groundwater Management Regulations [N]. China Water Resources News, 2021-11-23(002) (in Chinese)
