基于最大熵-无限边坡模型的降雨诱发浅层黄土滑坡稳定性评价方法研究

刘凡; 邓亚虹; 慕焕东; 钱法桥

doi:10.16030/j.cnki.issn.1000-3665.202207050

基于最大熵-无限边坡模型的降雨诱发浅层黄土滑坡稳定性评价方法研究

doi: 10.16030/j.cnki.issn.1000-3665.202207050

刘凡^{1, 2, 3,},
邓亚虹^{1, 2, ,},
慕焕东⁴,
钱法桥^{1, 2, 3}

1.
长安大学地质工程与测绘学院，陕西西安　710054
2.
自然资源部矿山地质灾害成灾机理与防控重点实验室，陕西西安　710054
3.
陕西省地质调查院，陕西西安　710068
4.
西安理工大学，陕西西安　710048

基金项目: 陕西省公益性地质调查项目（202101）；国家自然科学基金项目（41772275）；陕西省教育厅科学研究计划专项项目（20JK0801）；陕西省自然科学基础研究计划一般项目（2022JQ-289）；

详细信息

作者简介:
刘凡（1997-），男，硕士研究生，主要从事地质灾害防治研究。E-mail：2020126091@chd.edu.cn

通讯作者:
邓亚虹（1978-），男，教授，博士研究生导师，主要从事工程地质与地质灾害防治研究。E-mail：dgdyh@chd.edu.cn

计量
- 文章访问数: 9
- HTML全文浏览量: 4
- PDF下载量: 4
- 被引次数: 0
出版历程
- 收稿日期: 2022-07-29
- 录用日期: 2022-10-21
- 修回日期: 2022-10-13

A study of the stability evaluation method of rainfall-induced shallow loess landslides based on the Maxent-Sinmap slope model

LIU Fan^{1, 2, 3
,},
DENG Yahong^{1, 2
, ,},
MU Huangdong⁴,
QIAN Faqiao^{1, 2, 3}

1.
College of Geology Engineering and Geomatics, Chang’an University, Xi’an, Shaanxi　710054, China
2.
Key Laboratory of Mine Geological Hazards Mechanism and Control, Xi’an, Shaanxi　710054, China
3.
Shaanxi Institute of Geological Survey, Xi’an, Shaanxi　710068, China
4.
Institute of Geotechnical Engineering, Xi’an University of Technology, Xi’an, Shaanxi　710048, China

摘要

摘要: 针对Sinmap模型在评价降雨作用下浅层黄土滑坡稳定性中存在的评价精度较低问题，基于最大熵模型（Maxent）对Sinmap模型评价进行改进，构建了一种基于Maxent-Sinmap模型评价降雨作用下区域性浅层降雨型黄土滑坡稳定性方法。以黄土滑坡高发区志丹县为例，利用野外及室内相关工作获取地形、岩土体力学参数及地质灾害等相关数据，通过Maxent模型获取主要环境变量实现分区，在此基础上通过Sinmap模型对降雨作用下浅层黄土滑坡稳定性进行评价。研究结果如下：基于Maxent模型得到志丹县内坡度（27.1%）、降雨量（20.3%）、地貌（18.8%）、道路缓冲区（18.7%）及植被覆盖率（6.2%）等对历史灾点的贡献率。相较于传统Sinmap模型，该模型不稳定区域灾点密度分别提高了17.26%（小雨）、16.54%（中雨）、17.39%（大雨）、14.20（暴雨）、12.96%（大暴雨）。Maxent-Sinmap模型计算结果相较于Sinmap模型计算结果具有更大的稳定区域，且稳定区的扩大区无历史灾点分布。表明该模型具有更高精度及更可靠的结果，可以更好的为区域性浅层降雨型滑坡评价提供科学依据。
- Maxent-Sinmap /
- 降雨作用 /
- 区域性 /
- 浅层黄土滑坡 /
- 稳定性评价
Abstract: To address the problem of low evaluation accuracy of the Sinmap model in evaluating the stability of shallow loess landslides under the action of rainfall, a method based on the Maxent-Sinmap model is constructed to evaluate the stability of regional shallow rainfall loess landslides under the action of rainfall by improving the evaluation of the Sinmap model based on the maximum entropy model. Zhidan County, an area with a high incidence of loess landslides, is taken as an example. Relevant data on topography, geotechnical parameters and geological hazards are obtained by using field and indoor related work, and the main environmental variables are gained through the Maxent model to realize zoning. On the basis of these, the stability of shallow loess landslides under the action of rainfall is evaluated through the Sinmap model. The results indicate that the contribution of slope (27.1%), rainfall (20.3%), landform (18.8%), road buffers (18.7%) and vegetation cover (6.2%) to historical disaster sites within Zhidan County are obtained based on the Maxent model. Compared to the traditional Sinmap model, the density of unstable areas increases by 17.26% (light rainfall), 16.54% (moderate rainfall), 17.39% (heavy rainfall), 14.20 (rainstorm) and 12.96% (downpour), respectively. The results of the Maxent-Sinmap model have a larger stable area than those of the Sinmap model, and there is no historical disaster distribution in the expanded area of the stable area. The model has higher accuracy and more reliable results, which can provide a better scientific basis for the evaluation of regional shallow rainfall landslides.
- Maxent-Sinmap /
- rainfall /
- regional /
- shallow loess landslide /
- stability evaluation

HTML全文

图 1 志丹县历史滑坡分布图

Figure 1. Distribution of historical landslides in Zhidan County

下载: 全尺寸图片幻灯片

图 2 志丹县地质灾害易发性评价图

Figure 2. Evaluation map of geological disaster susceptibility in Zhidan County

下载: 全尺寸图片幻灯片

图 3 模型验证ROC曲线图

Figure 3. Model validation ROC curve

下载: 全尺寸图片幻灯片

图 4 影响因子贡献率图

Figure 4. Impact factor contribution

下载: 全尺寸图片幻灯片

图 5 主要影响因子响应曲线

Figure 5. Response of the main influence factors

下载: 全尺寸图片幻灯片

图 6 志丹县校准区图

Figure 6. Zoning map of calibration area in Zhidan County

下载: 全尺寸图片幻灯片

图 7 分区情况下不同降雨下面积变化

Figure 7. Area variation under different rainfall in the zoning situation

下载: 全尺寸图片幻灯片

图 8 分区计算模型地表稳定性指数图

Figure 8. Surface stability index map of the partition calculation model

下载: 全尺寸图片幻灯片

图 9 未分区情况下不同降雨下面积变化

Figure 9. Change in area under different rainfall without zoning

下载: 全尺寸图片幻灯片

图 11 研究区滑坡稳定性评价结果验证

Figure 11. Verification of landslide stability evaluation results in the study area

下载: 全尺寸图片幻灯片

图 10 未分区计算模型地表稳定性指数图

Figure 10. Surface stability index of the non-partitioned calculation model

下载: 全尺寸图片幻灯片

图 12 不同降雨条件下稳定区扩大区示意图

Figure 12. Schematic diagrams of the expansion area of the stable area under different rainfall conditions

下载: 全尺寸图片幻灯片

表 1 稳定性分级

Table 1. Stability classification

稳定性级别	稳定性指数	稳定性
1	SI≥1.5	极稳定区
2	1.5≥SI＞1.25	稳定区
3	1.25≥SI＞1.0	基本稳定区
4	1.0≥SI＞0.5	潜在不稳定区
5	0.5≥SI＞0	不稳定区
6	SI=0	极不稳定区

下载: 导出CSV

表 2 不同降雨量下的T/R参数值^[31]

Table 2. T/R parameter values under different rainfall

降雨级别	降雨量值（mm·d⁻¹）	T/R下限	T/R上限
小雨	0.1～9.9	1000	3000
中雨	10～24.9	573	1270
大雨	25～49.9	344	1032
暴雨	50～99.9	172	516
大暴雨	100～200	86	258

下载: 导出CSV

表 3 研究区分区岩土体物理力学参数

Table 3. Physical and mechanical parameters of rock and soil mass in the study area

区域	重力加速度（m·s⁻²）	湿度（%）	黏聚力（C）		内摩擦角（°）		土体密度（kg·m⁻³）
区域	重力加速度（m·s⁻²）	湿度（%）	上限	下限	上限	下限	土体密度（kg·m⁻³）
低降雨黄土丘陵区	9.81	15	0.2	0.4	25	40	1750
低降雨土石山区	9.81	15	0.28	0.54	31	55	1870
高降雨黄土丘陵区	9.81	18	0.2	0.4	30	50	1520
高降雨土石山区	9.81	18	0.28	0.54	31	55	1870

下载: 导出CSV

表 4 研究区总区域岩土体物理力学参数

Table 4. Physical and mechanical parameters of rock and soil mass in the study area

区域	重力加速度（m·s⁻²）	湿度（%）	黏聚力（C）		内摩擦角（°）		土体密度（kg·m⁻³）
区域	重力加速度（m·s⁻²）	湿度（%）	上限	下限	上限	下限	土体密度（kg·m⁻³）
研究区	9.81	16	0.2	0.54	25	55	1728

下载: 导出CSV

表 5 研究区分区计算结果汇总

Table 5. Summary of zonal calculation results in the study area

降雨量稳定等级	R=8.6 mm		R=15 mm		R=25 mm		R=50 mm		R=100 mm
降雨量稳定等级	面积（km²）	滑坡数	面积（km²）	滑坡数	面积（km²）	滑坡数	面积（km²）	滑坡数	面积（km²）	滑坡数
极稳定	2266.3	59	2108.9	45	1917.2	39	1655.7	29	1435.5	21
稳定	478.9	46	496.9	43	507.8	27	487.6	20	413.1	13
基本稳定	471.7	36	515.1	46	551.6	53	567.5	44	581.6	26
潜在不稳定	409.2	58	488.7	64	614.2	75	819.7	89	984.3	101
不稳定	56.7	11	71.1	12	88.7	16	142.9	26	243.7	44
极不稳定	5.3	1	6.7	1	7.4	1	12.1	3	23.2	6

下载: 导出CSV

表 6 研究区未分区计算结果汇总

Table 6. Summary of calculation results without partitions in the study area

降雨量	R=8.6mm		R=15mm		R=25mm		R=50mm		R=100mm
稳定性等级	面积（km²）	滑坡个数	面积（km²）	滑坡个数	面积（km²）	滑坡个数	面积（km²）	滑坡个数	面积（km²）	滑坡个数
极稳定	2128.4	55	1970.3	42	1782.3	35	1545.8	27	1354.6	20
稳定	508.1	46	516.7	44	517	30	476.7	20	392.5	14
基本稳定	527.8	39	568.9	47	591.6	54	579.7	45	564.3	26
潜在不稳定	554.6	70	660.4	76	822.1	89	1099.0	113	1361.4	141
不稳定	5.8	1	8.4	2	11.7	3	23.4	6	51.7	10
极不稳定	0	0	0	0	0	0	0.1	0	0.2	0

下载: 导出CSV
